Product Details

SMA Jack (Female) Straight Bulkhead Cable Connector

Order No:SMA2EA50-0047C/91
Product Name:Cable Solder
Series:SMA
Gender:Jack (Female)
Configuration:Straight
Panel Mounting:Hexagonal Flange With Nut
Suitable Cable:RSR-047
Backend Type:Cable Solder
Application Field:Communication
Rsonl P/N:SMA2EA50-0047C/91

Product Introduction

The SMA2EA50-0047C/91 is a SMA jack female coaxial bulkhead connector with an interface type that suits RSR-047, RSF-047, RSF-047-FEP and RSF-047-PVC. Its attachment method is solder or crimp for the pin and solder for the cable. This connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.

The SMA2EA50-0047C/91 has a beryllium copper pin with gold-nickel-phosphorus alloy plating and a brass body with gold-nickel-phosphorus alloy plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our SMA jack coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).

Rosnol's SMA2EA50-0047C/91 bulkhead female SMA RF connector has a maximum frequency of 18 GHz and a max. VSWR of 1.25 or min. Return Loss of 19.1 dB. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.

Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.

LMR is a Trademark of Times Microwave
