Product Details
4.1-9.5 Plug (Male) Right Angle Connector Solder Attachment
| Order No： | MD1E59-0141A／144 |
| Product Name： | Cable Solder |
| Series： | 4.1-9.5 |
| Gender： | Plug (Male) |
| Configuration： | Right Angle |
| Captivation： | Mechanical Captivation |
| Suitable Cable： | EF402 |
| Backend Type： | Cable Solder |
| Application Field： | Communication |
| Rsonl P/N： | MD1E59-0141A／144 |
Product Introduction
The MD1E59-0141A／144 is a right angle 4.1-9.5 male coaxial connector with an interface type that suits RSR-141, RSF-141, EF402, RFX-141. Its attachment method i for the pin and Solder for the cable. This connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a 90 degree elbow connector configuration.
The MD1E59-0141A／144 has a Brass pin with Gold plating and a Brass body with Copper-Tin-Zinc Alloy plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our right angle 4.1-9.5 plug coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s MD1E59-0141A／144 right angle 4.1-9.5 male RF connector has a maximum frequency of 6 GHz and a max. VSWR of 1.20 or min. Return Loss of 20.83 dB. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
