Product Details
Precision SMA (Female) Straight 4-Hole Panel Cable Jack, DC-26.5 GHz
| Order No： | PCA2EBF50-0047B/9Q |
| Product Name： | Cable Solder |
| Series： | Precision SMA |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 4-Hole Flange |
| Flange Dimension： | 9.53 X 9.53 |
| Suitable Cable： | RSF-047-FEP |
| Backend Type： | Coaxial End |
| Application Field： | Test & Measuremen |
| Rsonl P/N： | PCA2EBF50-0047B/9Q |
Product Introduction
The PCA2EBF50-0047B/9Q is a Precision SMA female 4 hole panel flange coaxial connector with an interface type that suits RSR-047, RSF-047, RSF-047-FEP, RSF-047-PVC. Its attachment method is solder for the pin and solder for the cable. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The PCA2EBF50-0047B/9Q has a beryllium copper pin with gold plating (nickel underplated) and a Stainless Steel body with gold plating (nickel underplated). Similar to almost all of our countless other millimeter wave, microwave and RF components, our Precision SMA jack terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's PCA2EBF50-0047B/9Q four hole panel flange female Precision SMA RF connector has a maximum frequency of 26.5 GHz and a max. VSWR of 1.40 or min. Return Loss of 15.56 dB. As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001) factory. Customization (material, plating, body, etc.) is possible upon request.
LMR is a Trademark of Times Microwave
