Product Details
2.92mm Jack (Female) Bulkhead Mount Connector
| Order No： | K2FA50-1426A/9X |
| Product Name： | Bulkhead Receptacle |
| Series： | 2.92mm |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Backend Type： | Coaxial End |
| Application Field： | Communication |
| Rsonl P/N： | K2FA50-1426A/9X |
Product Introduction
The K2FA50-1426A/9X is a 2.92mm female coaxial bulkhead connector with a coaxial end interface . This bulkhead replaceable connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The K2FA50-1426A/9X has a beryllium copper pin with gold plating (nickel underplated) and a stainless steel body with passivated plating . Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.92mm jack bulkhead replaceable coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's K2FA50-1426A/9X bulkhead female 2.92mm RF connector has a maximum frequency of 40 GHz and a max. VSWR of 1.20 or min. Return Loss of 20.83 dB. As a result, this high-quality bulkhead replaceable is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
