The SMA1D50-G316A/111 is a SMA male coaxial connector with an interface type that suits RG-174, RG-188A, RG-316, LMR-100, RNL-100, BELDEN 7805. Its attachment method is crimp or solder for the pin and clamp for the cable. This connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The SMA1D50-G316A/111 has a brass pin with gold plating (nickel underplated) and a brass body with gold plating (nickel underplated). Similar to almost all of our countless other millimeter wave, microwave and RF components, our SMA plug coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's SMA1D50-G316A/111 male SMA RF connector has a maximum frequency of 12.4 GHz and a max. VSWR of 1.20 or min at 2.5 to 5 GHz. Return Loss of 20.1 dB. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001) factory. Customization (material, plating, body, etc.) is possible upon request.
LMR is a Trademark of Times Microwave
