Product Details
3.5mm Straight Cable Plug
| Order No： | PC1K50-0420B/9XX |
| Product Name： | Cable Solder Clamp |
| Series： | 3.5mm |
| Gender： | Plug (Male) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Suitable Cable： | EW0420 |
| Backend Type： | Cable Solder Clamp |
| Application Field： | Communication |
| Rsonl P/N： | PC1K50-0420B/9XX |
Product Introduction
The PC1K50-0420B/9XX is a RPC 3.5 male coaxial connector with an interface type that suits EW0420. Its attachment method is Plug-in for the pin and Solder Clamp for the cable. This connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The PC1K50-0420B/9XX has a Beryllium Copper pin with Gold plating(Nickel underplated) plating and a Stainless Steel body with Gold plating(Nickel underplated) plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our RPC 3.5 plug coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s PC1K50-0420B/9XX RPC3.5 male RF connector has a maximum frequency of 26.5 GHz and a max. VSWR of 1.25 or min. Return Loss of 19.08 dB. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
LMR is a Trademark of Times Microwave
