Product Details
2.4mm Compression Mount Jack High Speed CPW/Microstrip or Stripline Options
| Order No： | Q2L50-1092A/9X |
| Product Name： | PCB Compression Mount |
| Series： | 2.4mm |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | PCB Flange With Nut |
| Backend Type： | Coaxial End |
| Application Field： | Communication |
| Rsonl P/N： | Q2L50-1092A/9X |
Product Introduction
The Q2L50-1092A/9X is a 2.4mm female compression mount pcb connector. This vertical launch connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight coaxial connector configuration.
The Q2L50-1092A/9X has a Beryllium Copper pin with Gold plating (Nickel underplated) plating and a Stainless Steel body with Passivated plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.4mm plug compression mount is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s Q2L50-1092A/9X compression mount 2.4mm female RF connector has a maximum frequency of 50 GHz and a max. VSWR of 1.20 GHz or min. Return Loss of 20.83 dB. As a result, this high-quality stripline launch is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
