Product Details
Precision SMA Straight Field Replaceable Jack
| Order No： | PCA2BF50-0018A/9X |
| Product Name： | Field Replaceable |
| Series： | Precision SMA |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 4-Hole Flange |
| Flange Dimension： | 12.7 X 12.7 |
| Backend Type： | Accepts Pin ∅0.46 [.018] |
| Application Field： | Test & Measuremen |
| Rsonl P/N： | PCA2BF50-0020B/9X |
Product Introduction
The PCA2BF50-0018A/9X is a Precision SMA female 4 hole panel flange coaxial connector which accepts a ∅0.46mm[.018in] pin. This field replaceable connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The PCA2BF50-0018A/9X has a Beryllium Copper pin with Gold plating(Nickel underplated) and a Stainless Steel body with Passivated plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our Precision SMA jack field replaceable coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s PCA2BF50-0018A/9X four hole panel flange Precision SMA female RF connector has a maximum frequency of 27 GHz and a max. VSWR of 18 or min at 1.10 GHz or min. Return Loss of 26.44 dB. As a result, this high-quality field replaceable is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
