Product Details
N Straight Panel Receptacle Jack Low PIM
| Order No： | N2GFE50-4364B/90-LP |
| Product Name： | Panel Receptacle |
| Series： | N |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 4-Hole Flange |
| Backend Type： | Special End |
| Application Field： | Communication |
| Rsonl P/N： | N2GFE50-4364B/94-LP |
Product Introduction
The N2GFE50-4364B/90-LP is a N female 4 hole panel flange coaxial connector with a Special End interface. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The N2GFE50-4364B/90-LP has a Beryllium Copper pin with gold plating ((≥100 microinches; per MIL-G-45204; type I; grade C; class 2) plating and a brass body with Silver plating plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our N female terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s N2GFE50-4364B/90-LP four hole panel flange N female RF connector has a maximum frequency of 5 GHz and a max. VSWR of 1.3 at 2.3 GHz or min. Return Loss of 28.30 dB. As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
