Product Details
N Straight Panel Receptacle Jack (Solder End)
| Order No： | N2GFB50-2500C/H3 |
| Product Name： | Panel Receptacle |
| Series： | N |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 4-Hole Flange |
| Flange Dimension： | 25.4 X 25.4 |
| Backend Type： | Solder End |
| Application Field： | Communication |
| Rsonl P/N： | N2GFB50-2500C/H3 |
Product Introduction
The N2GFB50-2500C/H3 is a N female 4 hole panel flange coaxial connector with a Solder End interface. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The N2GFB50-2500C/H3 has a Phosphor Bronze pin with Gold plating(Nickel underplated) and a Brass body with Nickel plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our N plug terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s N2GFB50-2500C/H3 four hole panel flange N female RF connector has a maximum frequency of 11 GHz and a max. As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
