Product Details
SMA Straight Panel Receptacle Jack (Solder End)
| Order No： | SMA2GFB50-1460A/9Q |
| Product Name： | Panel Receptacle |
| Series： | SMA |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 4-Hole Flange |
| Backend Type： | Cable Solder |
| Application Field： | Communication |
| Rsonl P/N： | SMA2GFB50-1460A/9Q |
Product Introduction
The SMA2GFB50-1460A/9Q is a SMA female 4 hole panel flange coaxial connector with a Solder End interface. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The SMA2GFB50-1460A/9Q has a Beryllium Copper pin with Gold plating(Nickel underplated) and a Stainless Steel body with Gold plating(Nickel underplated). Similar to almost all of our countless other millimeter wave, microwave and RF components, our SMA plug terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s SMA2GFB50-1460A/9Q four hole panel flange SMA female RF connector has a maximum frequency of 18 GHz and a max. As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
