Product Details
2.92mm Plug (Male) Straight Cable Solder
| Order No： | K1E50-0085A/91X |
| Product Name： | Cable Solder |
| Series： | 2.92mm |
| Gender： | Plug (Male) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Suitable Cable： | Belden 1671A |
| Backend Type： | Cable Solder |
| Application Field： | Test & Measuremen |
| Rsonl P/N： | K1E50-0085A/91X |
Product Introduction
The K1E50-G058A/91X is a 2.92mm male coaxial connector with an interface type that suits RSR-085, RSF-085, RSF-085-FEP, UT 85, RG 405/U, RTK- FS 085, RTK- Flex 405, BELDEN 1671A. Its attachment method is plug-in for the pin and crimp for the cable. This connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The K1E50-G058A/91X has a beryllium copper pin with gold plating (nickel underplated) and a brass body with gold plating (nickel underplated). Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.92mm plug coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's K1E50-G058A/91X male 2.92mm RF connector has a maximum frequency of 40 GHz and a max. VSWR of 1.30 or min. Return Loss of 17.69 dB. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001) factory. Customization (material, plating, body, etc.) is possible upon request.
LMR is a Trademark of Times Microwave
