Product Details
TNC Jack (Female) Straight Bulkhead Connector
| Order No： | TNC2FB50-2670A/HX |
| Product Name： | Bulkhead Receptacle |
| Series： | TNC |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | Round Flange With Nut |
| Backend Type： | Solder End |
| Application Field： | Communication |
| Rsonl P/N： | TNC2FB50-2670A/HX |
Product Introduction
The TNC2FB50-2670A/HX is a TNC jacl female coaxial bulkhead connector with a solder end interface . This bulkhead replaceable connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The TNC2FB50-2670A/HX has a phosphor pronze pin with gold plating (nickel underplated) and a stainless steel body with passivated plating . Similar to almost all of our countless other millimeter wave, microwave and RF components, our TNC jacl bulkhead replaceable coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's TNC2FB50-2670A/HX bulkhead female TNC RF connector has a maximum frequency of 11 GHz and a max. As a result, this high-quality bulkhead replaceable is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
LMR is a Trademark of Times Microwave
