Product Details
SMA Jack (Female) Straight Compression Mount PCB Connector
| Order No： | SMA2LA50-0963A/9X |
| Product Name： | PCB Compression Mount |
| Series： | SMA |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Backend Type： | Coaxial End |
| Application Field： | Communication |
| Rsonl P/N： | SMA2LA50-0963A/9X |
Product Introduction
The SMA2LA50-0963A/9X is a SMA female compression mount pcb connector. This vertical launch connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight coaxial connector configuration.
The SMA2LA50-0963A/9X has a beryllium copper pin with gold plating (nickel underplated) and a stainless steel body with passivated plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our SMA jack compression mount is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's SMA2LA50-0963A/9X compression mount female SMA RF connector has a maximum frequency of 27 GHz and a max. As a result, this high-quality stripline launch is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
