Product Details
Bulkhead adaptor plug/jack N plug (male) / MCX jack (female)
| Order No： | AD-N1M25A-BH/944-91 |
| Product Name： | Adaptor |
| Series： | MCX |
| Gender： | Jack (Female) |
| Series 2： | N |
| Gender 2： | Plug (Male) |
| Configuration： | Straight |
| Application Field： | Communication |
| Rosnol P/N： | AD-N1M25A-BH/944-91 |
Product Introduction
The AD-N1M25A-BH/944-91 is a N male to MCX female coaxial bulkhead adaptor. This between-series precision adaptor design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight adaptor configuration.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our N plug to MCX jack coaxial adapter is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s AD-N1M25A-BH/944-91 bulkhead N male to MCX female RF adapter has a maximum frequency of 6 GHz and a max. VSWR of 1.20 or min. Return Loss of 20.8 dB. As a result, this high-quality adaptor is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
