Product Details
7/16 Jack (Female) / 7/16 Jack (Female) 4-Hole Panel Adaptor, DC-7.5 GHz, VSWR ≤ 1.20
| Order No： | AD-D2D25A-PF/H4-H4 |
| Product Name： | Adaptor |
| Series： | 7-16 |
| Gender： | Jack (Female) |
| Series 2： | 7-16 |
| Gender 2： | Jack (Female) |
| Configuration： | Straight |
| Panel Mounting： | 4-Hole Flange |
| Application Field： | Communication |
| Rosnol P/N： | AD-D2D25A-PF/H4-H4 |
Product Introduction
The AD-D2D25A-PF/H4-H4 is a 7/16 female to 7/16 female 4 hole panel flange coaxial adaptor. This in-series precision adaptor design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight adaptor configuration.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our 7/16 jack to 7/16 jack coaxial adapter is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's AD-D2D25A-PF/H4-H4 4 hole panel flange female 7/16 to female 7/16 RF adapter has a maximum frequency of 7.5 GHz. VSWR of 1.20 or min. Return Loss of 20.8 dB. As a result, this high-quality adaptor is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001) factory. Customization (material, plating, body, etc.) is possible upon request.
