Product Details
2.4mm Plug (Male) to 2.92mm Jack (Female) Panel 4 Hole Flange Mount Adapter
| Order No： | AD-Q1K25A-PF/9XX-9X |
| Product Name： | Adaptor |
| Series： | 2.92mm |
| Gender： | Plug (Male) |
| Series 2： | 2.4mm |
| Gender 2： | Jack (Female) |
| Configuration： | Straight |
| Panel Mounting： | 4-Hole Flange |
| Application Field： | Test & Measurement |
Product Introduction
The AD-Q1K25A-PF/9XX-9X is a 2.4mm male to 2.92mm female 4 hole panel flange coaxial adaptor. This between-series precision adaptor design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight adaptor configuration.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.4mm plug to 2.92mm jack coaxial adapter is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s AD-Q1K25A-PF/9XX-9X four hole panel flange 2.4mm male to 2.92mm female RF adapter has a maximum frequency of 40 GHz and a max. VSWR of 1.15 GHz or min. Return Loss of 23.13 dB. As a result, this high-quality adaptor is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
