Product Details
2.92mm Jack (Female) Connector Solder Attachment 2 Hole Flange Mount Stub Terminal, 8.64mm [.340 inc
| Order No： | K2GTA50-1450D/9X |
| Product Name： | Panel Receptacle |
| Series： | 2.92mm |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 2-Hole Flange |
| Backend Type： | Coaxial End |
| Application Field： | Communication |
| Rsonl P/N： | K2GTA50-1450D/9X |
Product Introduction
The K2GTA50-1450D/9X is a 2.92mm female 2 hole panel flange coaxial connector with a coaxial end interface. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The K2GTA50-1450D/9X has a Beryllium Copper pin with Gold plating, 3 μinch
(Non-magnetic nickel-phosphorus underplating, 80 μinch) plating and a Stainless Steel body with Passivated plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.92mm jack terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s K2GTA50-1450D/9X two hole panel flange 2.92mm female RF connector has a maximum frequency of 40 GHz and a max. VSWR of 1.20 or min. Return Loss of 20.83 dB. As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
