Product Details
SMA Right Angle Cable Plug
| Order No： | SMA1C59-G316A/11X |
| Product Name： | Cable Crimp |
| Series： | SMA |
| Gender： | Plug (Male) |
| Configuration： | Right Angle |
| Suitable Cable： | RNL-100 |
| Backend Type： | Cable Crimp |
| Application Field： | Communication |
| Rsonl P/N： | SMA1C59-G316A/11X |
Product Introduction
The SMA1C59-G316A/11X is a SMA male coaxial connector with an interface type that suits RG 316/U, RG 174 A/U, RG 188, G 02232, BELDEN 7805. Its attachment method is Soldered for the pin and Crimped for the cable. This connector design has an impedance of [阻抗數值] Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The SMA1C59-G316A/11X has a Brass pin with Gold plating(Nickel underplated) plating and a Brass body with Gold plating(Nickel underplated) plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our SMA plug coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s SMA1C59-G316A/11X SMA male RF connector has a maximum frequency of 6 GHz and a max. VSWR of 1.20 or min. Return Loss of 20.83 dB. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
LMR is a Trademark of Times Microwave
