Product Details
Precision SMA Plug (Male) to Precision SMA Jack (Female) DC Block
| Order No： | DB-PCA1PCA25A-26G100V/9XX |
| Product Name： | DC-Block |
| Series： | Precision SMA |
| Gender： | Jack (Female) |
| Series 2 (Without Termination)： | Precision SMA |
| Gender 2 (Without Termination)： | Plug (Male) |
| DC Input Voltage： | 100 Volt |
| Application Field： | Test & Measurement |
| Rosnol P/N： | DB-PCA1PCA25A-26G100V/9XX |
Product Introduction
The DB-PCA1PCA25A-26G100V/9XX-9X is a Precision SMA male to Precision SMA female inner DC block. This direct current block relies on the inner conductor and has a voltage rating of 50 V Max.The DB-PCA1PCA25A-27G50V／9XX-9X coaxial DC block has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight body configuration made of Stainless Steel with Passivated plating.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our Precision SMA Plug to Precision SMA Jack inner coaxial direct current block is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s DB-PCA1PCA25A-26G100V/9XX-9X is a Precision SMA male to Precision SMA female RF DC block has a maximum frequency of 26 GHz and a max. VSWR of 1.32 GHz or min. Return Loss of 17.21 dB. As a result, this high-quality inner direct current block is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
