Product Details
4.1-9.5 (Female) Termination Jack
| Order No： | T-MD25-6G2WA/H4 |
| Product Name： | Termination |
| Series： | 4.1-9.5 |
| Gender： | Jack (Female) |
| Frequency： | 6 GHz |
| Power： | 2 Watt |
| Application Field： | Communication |
| Rosnol P/N： | T-MD25-6G2WA/H4 |
Product Introduction
The T-MD25-6G2WA/H4 is a 4.1-9.5 female coaxial 2W termination. This RF load termination design has an impedance of 50 Ohm and is fully compliant to RF industry standards. The 2W 4.1-9.5 male termination has a straight body configuration.
The T-MD25-6G2WA/H4 dummy load has a phosphor bronze pin with gold plating (nickel underplated) plating and a brass body with copper-tin-zinc alloy plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our female coax terminator is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s T-MD25-6G2WA/H4 RF termination has a maximum frequency of 6 GHz and a max. VSWR of 1.15 GHz or min. Return Loss of 23.13 Db. As a result, this high-quality termination is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
