Product Details
DC Block plug/jack BNC plug (male) / BNC jack (female)
| Order No： | DB-B1B25A-3G50V／H44-H4 |
| Product Name： | DC-Block |
| Series： | BNC |
| Gender： | Jack (Female) |
| Series 2 (Without Termination)： | BNC |
| Gender 2 (Without Termination)： | Plug (Male) |
| Frequency： | 3 GHz |
| DC Input Voltage： | 50 Volt |
| Application Field： | Communication |
| Rosnol P/N： | DB-B1B25A-3G50V／H44-H4 |
Product Introduction
The DB-B1B25A-3G50V／H44-H4 is a BNC male to BNC female inner DC block. This direct current block relies on the inner conductor and has a voltage rating of 50V.
The DB-B1B25A-3G50V／H44-H4 coaxial DC block has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight body configuration made of Brass with copper-tin-zinc alloy plating.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our BNC plug to BNC jack inner coaxial direct current block is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s DB-B1B25A-3G50V／H44-H4 BNC male to BNC female RF DC block has a maximum frequency of 3 GHz and a max. VSWR of 1.20 at 3 GHz or min. Return Loss of 0.2 dB at 3 GHz. As a result, this high-quality inner direct current block is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
