Product Details
N 50Ω Jack (Female) to N 75Ω Jack (Female) Impedance Matching Pads
| Order No： | MP-N25N27A-2G/H4-H4 |
| Product Name： | Impedance Matching Pad |
| Series： | N |
| Gender： | Jack (Female) |
| Series 2 (Without Termination)： | N |
| Gender 2 (Without Termination)： | Jack (Female) |
| Frequency： | 2 GHz |
| Power： | 0.7 Watt |
| Application Field： | Test & Measurement |
| Rosnol P/N： | MP-N25N27A-2G/H4-H4 |
Product Introduction
The MP-N25N27A-2G/H44-H4 is an N female 50 Ohm to N female 75 Ohm impedance matching pads. This coaxial matching pad has an input power rating of 0.7W Avg. @40°C and an attenuation of 5.7 dB or min. The MP-N25N27A-2G/H44-H4 RF impedance matching pad has an impedance of 50 Ohm at its N end and 75 Ohm at its N end. It has a straight body configuration made of brass with copper-tin-zinc alloy plating and is fully compliant to RF industry standards.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our N jack to N jack radio frequency impedance matching pad is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's MP-N25N27A-2G/H44-H4 female N to female N RF DC block has a maximum frequency of 2 GHz and a max. VSWR of 1.25 or min. Return Loss of 19.1 dB. As a result, this high-quality impedance matching pad is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
