Product Details
SMA Straight Panel Jack (Female) 2 Hole Flange | Flat End | Mechanical Captived
| Order No： | SMA2GTD50-1200A/91 |
| Product Name： | Panel Receptacle |
| Series： | SMA |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 2-Hole Flange |
| Backend Type： | Flat End |
| Application Field： | Communication |
| Rsonl P/N： | SMA2GTD50-1200A/91 |
Product Introduction
The SMA2GTD50-1200A/91 is a SMA Straight Panel Receptacle female 2 hole panel flange coaxial connector with a flat end interface. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The SMA2GTD50-1200A/91 has a Beryllium Cpooer pin with Gold plating(Nickel underplated) plating and a Brass body with Gold plating(Nickel underplated)] plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our SMA Straight Panel Receptacle jack terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s SMA2GTD50-1200A/91 two hole panel flange SMA Straight Panel Receptacle female RF connector has a maximum frequency of 18 GHz and a max. VSWR of 1.25 GHZ or min. Return Loss of 19.08 dB. As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
