Product Details
SMC Straight Cable Plug
| Order No： | SMC1D50-G316A/911 |
| Product Name： | Cable Clamp |
| Series： | SMC |
| Gender： | Plug (Male) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Suitable Cable： | RNL-100 |
| Backend Type： | Cable Clamp |
| Application Field： | Communication |
| Rsonl P/N： | SMC1D50-G316A／911 |
Product Introduction
The SMC1D50-G316A/911 is a SMC male coaxial connector with an interface type that suits RG-174, RG-188A, RG-316, LMR-100, RNL-100, BELDEN 7805. Its attachment method is Soldered for the pin and Clamped for the cable. This connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The SMC1D50-G316A/911 has a Beryllium Copper pin with Gold plating (Nickel underplated) and a Brass body with Gold plating (Nickel underplated). Similar to almost all of our countless other millimeter wave, microwave and RF components, our SMC male plug coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s SMC1D50-G316A/911 SMC male RF connector has a maximum frequency of 10 GHz and a max. VSWR of 1.22 or min. Return Loss of 20 dB. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
LMR is a Trademark of Times Microwave
