Product Details
SMA Right Angle Cable Plug
| Order No： | SMA1K59-MP533A/9XX |
| Product Name： | Cable Solder Clamp |
| Series： | SMA |
| Gender： | Plug (Male) |
| Configuration： | Right Angle |
| Captivation： | Mechanical Captivation |
| Backend Type： | Cable Solder Clamp |
| Application Field： | Communication |
| Rsonl P/N： | SMA1K59-MP533A/9XX |
Product Introduction
The SMA1K59-MP533A/9XX is a right angle SMA male coaxial connector with an interface type that suits MP533A, MP533B. Its attachment method is Soldered for the pin and Solder Clamp for the cable. This connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a 90 degree elbow connector configuration.
The SMA1K59-MP533A/9XX has a Beryllium Copper pin with Gold plating(Nickel underplated) and a Stainless Steel body with Passivated plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our right angle SMA plug coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s SMA1K59-MP533A/9XX right angle SMA male RF connector has a maximum frequency of 18 GHz and a max. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
LMR is a Trademark of Times Microwave
