Product Details
SMA 45 Degree Angle PCB Jack
| Order No： | SMA2I54-1971A/91 |
| Product Name： | PCB Through Holes Mount |
| Series： | SMA |
| Gender： | Jack (Female) |
| Configuration： | Right Angle |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | PCB Flange With Nut |
| Backend Type： | Coaxial End |
| Application Field： | Communication |
| Rsonl P/N： | SMA2I54-1971A/91 |
Product Introduction
The SMA2I54-1971A/91 is a right angle SMA female thru hole pcb connector. This thru hole connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a 90 degree elbow coaxial connector configuration.
The SMA2I54-1971A/91 has a Beryllium Copper pin with Gold plating(Nickel underplated) and a Brass body with Gold plating(Nickel underplated). Similar to almost all of our countless other millimeter wave, microwave and RF components, our R/A SMA jack thru hole mount is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s SMA2I54-1971A/91 RA thru hole SMA female RF connector has a maximum frequency of 18 GHz and a max. As a result, this high-quality through hole mount is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
