Product Details
SC Straight Panel Receptacle Jack With Flat End
| Order No： | SC2GFD50-2870A/9X |
| Product Name： | Panel Receptacle |
| Series： | SC |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 4-Hole Flange |
| Flange Dimension： | 25.4 X 25.4 |
| Backend Type： | Flat End |
| Application Field： | Communication |
| Rsonl P/N： | SC2GFD50-2870A/9X |
Product Introduction
The SC2GFD50-2870A/9X is a right angle SC female 4 hole panel flange coaxial connector with a Flat End interface. This field replaceable connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a 90 degree elbow connector configuration.
The SC2GFD50-2870A/9X has a Beryllium Copper pin with Gold plating(Nickel underplated) plating and a Stainless Steel body with Passivated plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our R/A SC jack field replaceable coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s SC2GFD50-2870A/9X RA four hole panel flange SC female RF connector has a maximum frequency of 11 GHz and a max. As a result, this high-quality field replaceable is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
