Product Details

SMA Compression Mount For Coplanar Waveguide or Microstrip trace Jack

Order No:SMA2LA50-0963B/91
Product Name:PCB Compression Mount
Series:SMA
Gender:Jack (Female)
Configuration:Straight
Captivation:Mechanical Captivation
Panel Mounting:2-Hole Flange
Backend Type:Coaxial End
Application Field:Communication
Rsonl P/N:SMA2LA50-0963B/91

Product Introduction

The SMA2LA50-0963B/91 is a SMA female compression mount pcb connector. This vertical launch connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight coaxial connector configuration.

The SMA2LA50-0963B/91 has a Beryllium Copper pin with Gold plating(Nickel underplated) and a Brass body with Gold plating(Nickel underplated). Similar to almost all of our countless other millimeter wave, microwave and RF components, our  SMA jack compression mount is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).

Rosnol’s SMA2LA50-0963B/91 compression mount SMA female RF connector has a maximum frequency of 18 GHz and a max. As a result, this high-quality stripline launch is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.

Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
