Product Details
Precision TNC Jack (Female) Cable Connector 4 Hole Flange
| Order No： | PCT2EBF50-0085A/9Q |
| Product Name： | Cable Solder |
| Series： | Precision TNC |
| Gender： | Jack (Female) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 4-Hole Flange |
| Suitable Cable： | Belden 1671A |
| Backend Type： | Cable Solder |
| Application Field： | Test & Measuremen |
| Rsonl P/N： | PCT2EBF50-0085A/9Q |
Product Introduction
The PCT2EBF50-0085A/9Q is a Precision TNC female 4 hole panel flange coaxial connector with an interface type that suits RSR-085, RSF-085, RSF-085-FEP, UT 85, RG 405/U, RTK- FS 085, RTK- Flex 405, BELDEN 1671A. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The PCT2EBF50-0085A/9Q has a Beryllium Copper pin with gold plating (nickel underplated) and a Stainless Steel body Gold plating(Nickel underplated). Similar to almost all of our countless other millimeter wave, microwave and RF components, our Precision TNC jack terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's PCT2EBF50-0085A/9Q four hole panel flange female Precision TNC RF connector has a maximum frequency of 18 GHz and a max. VSWR of 15 GHz or min. Return Loss of 19.08 dB As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
