4.3-10 Straight Panel Receptacle Plug Coaxial End (Low PIM)
| Order No： | 43101GFA50-5095A/144-LP |
| Product Name： | Panel Receptacle |
| Series： | 4.3-10 |
| Gender： | Plug (Male) |
| Configuration： | Straight |
| Captivation： | Mechanical Captivation |
| Panel Mounting： | 4-Hole Flange |
| Backend Type： | Coaxial End |
| Application Field： | Communication |
| Rsonl P/N： | 43101GFA50-5095A/144-LP |
Product Introduction
The 43101GFA50-5095A/144-LP is a 4.3-10 male 4 hole panel flange coaxial connector with a coaxial end interface. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.
The 43101GFA50-5095A/144-LP has a Brass pin with Gold plating(no nickel underplating) and a Brass body with Copper-Tin-Zinc Alloy plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our 4.3-10 plug terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s 43101GFA50-5095A/144-LP four hole panel flange 4.3-10 male RF connector has a maximum frequency of 12 GHz and a max. VSWR of 6 GHz or min. Return Loss of 20.83 dB. As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
