Product Details

7/16 Straight Panel Receptacle Jack Flat End

Order No:716-2GFD50-3720A/H4
Product Name:Panel Receptacle
Series:7-16
Gender:Jack (Female)
Configuration:Straight
Captivation:Mechanical Captivation
Panel Mounting:4-Hole Flange
Backend Type:Flat End
Application Field:Communication
Rsonl P/N:716-2GFD50-3720A/H4

Product Introduction

The 716-2GFD50-3720A/H4 is a 7/16 female 4 hole panel flange coaxial connector with a Flat End interface. This terminal connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.

The 716-2GFD50-3720A/H4 has a Phosphor Bronze pin with Gold plating(Nickel underplated) and a Brass body with Copper-Tin-Zinc Alloy plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our 7/16 jack terminal coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).

Rosnol’s 716-2GFD50-3720A/H4 four hole panel flange 7/16 female RF connector has a maximum frequency of 7.5 GHz and a max. As a result, this high-quality panel connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.

Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
