Product Details
Panel adaptor jack/jack SMA jack (female) / SMA jack (female)
| Order No： | AD-A2A25D-PF/9X-9X |
| Product Name： | Adaptor |
| Series： | SMA |
| Gender： | Jack (Female) |
| Series 2： | SMA |
| Gender 2： | Jack (Female) |
| Configuration： | Straight |
| Panel Mounting： | 4-Hole Flange |
| Application Field： | Communication |
| Rosnol P/N： | AD-A2A25D-PF/9X-9X |
Product Introduction
The AD-A2A25D-PF/9X-9X is a SMA female to SMA female 4 hole panel flange coaxial adaptor. This in-series precision adaptor design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight adaptor configuration.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our SERIES1 plug/jack to SERIES2 plug/jack coaxial adapter is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s AD-A2A25D-PF/9X-9X four hole panel flange SMA female to SMA female RF adapter has a maximum frequency of 18 GHz and a max. VSWR of 1.15 or min. Return Loss of 23.13 dB. As a result, this high-quality adaptor is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
