Product Details
Panel adaptor jack/jack Precision SMA jack (female) / Precision SMA jack (female)
| Order No： | AD-PCA2PCA25B-PFM2/9X-9X |
| Product Name： | Adaptor |
| Series： | Precision SMA |
| Gender： | Jack (Female) |
| Series 2： | Precision SMA |
| Gender 2： | Jack (Female) |
| Configuration： | Straight |
| Panel Mounting： | 4-Hole Flange |
| Application Field： | Test & Measurement |
| Rosnol P/N： | AD-PCA2PCA25B-PFM2/9X-9X |
Product Introduction
The AD-PCA2PCA25B-PFM2/9X-9X is a Precision SMA female to Precision SMA female 4 hole panel flange coaxial adaptor. This in-series precision adaptor design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight adaptor configuration.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our SERIES1 plug/jack to SERIES2 plug/jack coaxial adapter is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s AD-PCA2PCA25B-PFM2/9X-9X four hole panel flange Precision SMA female to Precision SMA female RF adapter has a maximum frequency of 27 GHz and a max. VSWR of 1.15 GHz or min. Return Loss of 23.13 dB. As a result, this high-quality adaptor is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
